ELGi EQ Series Rotary Screw Air Compressor
Fixed and variable speeds available, with 25 or 60 HP, and up to a 175 PSI rating. Optional 120 gallon tank with timer drain or dryer. 5 year warranty.
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The ELGi EQ Series Rotary Screw Air Compressor is a durable, reliable application solution in the most demanding conditions, with minimal maintenance requirements. A smart Neuron XT controller controls the EQ Series system, providing streamlined operation of advanced monitoring features. This technology helps to better safeguard against failures such as motor overload, reverse rotation of motor, as well as exceeding oil, temperature, and pressure safety thresholds. In cases where application demands fluctuate, the EQ Series can be configured with the Variable Frequency Drive (VFD) to adjust the compressor’s speed based on use case, reducing excess energy consumption. Units come in base or tank-mount configurations. The 120 gallon horizontal tank features an optional EGRD dryer and filters.
Overview and Features
Features
- Efficient TEFC motor
- Horsepower: 25 or 60 HP
- Capacities (depending on selection):
- Fixed speed: 78 to 284 CFM
- Variable speed: 31 to 78 through 77 to 284 CFM
- Pressure rating: 100, 125, 150, 175 PSI
- Control:
- Load/ Un-load regulation
- VFD
- Base or tank mounted models
- Tank mounted available with timer drain or refrigerated dryer with filters
- 120 gallon
- Ambient temperature: up to 122°F
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Drive | Fixed speed drive, Variable speed drive |
|---|---|
| Horsepower | 25 HP, 30 HP, 40 HP, 50 HP, 60 HP |
| Capacity | 111 CFM, 100 CFM, 87 CFM, 78 CFM, 134 CFM, 118 CFM, 109 CFM, 91 CFM, 47 to 111 CFM, 41 to 100 CFM, 39 to 87 CFM, 31 to 78 CFM, 57 to 134 CFM, 52 to 118 CFM, 47 to 109 CFM, 41 to 91 CFM, 191 CFM, 182 CFM, 144 CFM, 237 CFM, 209 CFM, 188 CFM, 284 CFM, 262 CFM, 227 CFM, 63 to 191 CFM, 55 to 182 CFM, 45 to 144 CFM, 63 to 237 CFM, 55 to 209 CFM, 45 to 188 CFM, 77 to 284 CFM, 55 to 262 CFM, 54 to 227 CFM |
| Pressure | 100 PSI, 125 PSI, 150 PSI, 175 PSI |
| Configuration | Base mount, Tank Mount |
| Tank Size | None, 120 gallon |
| Dryer Options | None, No dryer, tank timer drain only, With refrigerated dryer and filters |
| Voltage | 230/460/3/60, 460/3/60 |
