Ingersoll Rand RS-Series Variable Speed Rotary Screw Air Compressor
40 to 100 HP air-cooled compressors, 171 to 527 CFM capacities, IE3 premium TEFC motor
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Ingersoll Rand RS-Series variable speed rotary screw air compressor delivers optimum performance and reliability in a compact package. The Danfoss variable speed drive eliminates overheating and related component failures while the V-Shield technology uses premium PTFE hoses on all oil-carrying lines as well as O-ring face seal connections, reducing the risk of leaks and increasing hose lifespan.
Overview and Features
Features
- TEFC premium efficiency motor
- Up to 527 CFM capacity (depending on selected HP)
- Air cooled aftercooler
- Nema 12 electrics
- Package pre-filter
- Quiet enclosure down to 69dBA
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Dryer | None, Integrated air dryer (TAS) |
|---|---|
| Horsepower | 40 HP, 50 HP, 60 HP, 75 HP, 100 HP |
| Capacity | 195 CFM at 110 PSI, 183 CFM at 125 PSI, 171 CFM at 145 PSI, 231 CFM at 110 PSI, 217 CFM at 125 PSI, 203 CFM at 145 PSI, 195 CFM at 103 PSI, 183 CFM at 118 PSI, 171 CFM at 138 PSI, 231 CFM at 103 PSI, 217 CFM at 118 PSI, 203 CFM at 138 PSI, 302 to 250 CFM at 100 to 145 PSI, 400 to 331 CFM at 100 to 145 PSI, 527 to 445 CFM at 100 to 145 PSI |
| Voltage | 230/3/60, 460/3/60, 575/3/60 |
| Controller | Xe-70M Controller, Xe-70M ECO Module, XS-180 Controller |
| Additional Options | Power Outage Restart (PORO), Remote Pressure Transducer, Ultra FG Coolant, Ultra EL Coolant, Sealed Containment Base, Phase Monitor, Remote Sensing |
