Dekker Maxima 3K Series Single-Stage Liquid Ring Vacuum Pump
1050 to 13000 ACFM capacity single-stage vacuum pump with vacuum capabilities up to 29” HgV
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Dekker Maxima 3K Series Single-Stage Liquid Ring Vacuum Pump is designed to deliver efficient performance throughout the vacuum range. Its single-stage design features flat port plates mounted on each side of the impeller, allowing for variable discharge port operation. The heavy-duty impeller is reinforced with rings to enhance blade strength and pump durability. The pump comes with packed gland sealing, featuring a split ring gland that makes maintenance easy. Access plates on both sides of the pump allow for quick evaluation of clearance and easy boroscope inspection. Available in capacities ranging from 1050 to 13000 ACFM.
Overview and Features
Features
- 60 to 750 HP ranges available
- Variable discharge port
- Shaft sleeves standard
- Packed gland sealing standard
- Heavy-duty bearings mounted external to the pumping chamber
- Low operating speeds
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Horsepower | 60 to 125 HP, 75 to 150 HP, 100 to 200 HP, 125 to 250 HP, 200 to 400 HP, 250 to 600 HP, 350 to 750 HP |
|---|---|
| Capacity | 1050 to 1675 ACFM, 1500 to 2250 ACFM, 2125 to 3400 ACFM, 2925 to 4175 ACFM, 3600 to 6650 ACFM, 5550 to 9200 ACFM, 8000 to 13000 ACFM |
| GPM | 5 to 30 GPM, 13 to 42 GPM, 15 to 60 GPM, 18 to 88 GPM, 22 to 98 GPM, 20 to 138 GPM, 50 to 180 GPM |
| Connection Size / Type | 6" 150# flange, 8" 150# flange, 10" 150# flange, 12" 150# flange, 14" 150# flange, 16" 150# flange, 20" 150# flange |
