Champion Revolution HQ Series Two-Stage Piston Air Compressor
5 to 15 hp, splash lubricated reciprocating air compressor, R-Series compressor pump, quiet enclosure
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Champion Revolution Series Two-Stage Piston Air Compressor is designed with a quiet enclosure that uses 2” foam on external panels. Its R-Series compressor pump combines reliability and high performance into an enclosure that offers optimum cooling and low sound levels. This makes it ideal for applications requiring the technology of a reciprocating compressor but also lower sound levels, with dBA levels as low as 62 dBA.
Overview and Features
Features
- 5, 7.5, 10, and 15 HP
- 175 PSI pressure rating
- NEMA 1 Mounted Control Panel with hour meter and on/off switch
- Champion R-Series compressor pump
- Low Oil Level Monitor
- Air Cooled Aftercooler
- ASME inter-stage pressure relief valve for protection
- ODP NEMA 1760 RPM electric motor
- 10 Micron industrial grade intake filter
- ASME coded receiver
- 0 to 300 PSIG air pressure gauge on tank mounted models
- Available voltages:
- Single phase: 208-230
- Three phase: 208/230/460/575
- Airstation models available
- Mounted X Series dryer
- X Series pre-filter
- 3-way bypass valve
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Configuration | Base mount, Tank mount |
|---|---|
| Dryer | None, Mounted X Series dryer |
| Horsepower | 5 HP, 7.5 HP, 10 HP, 15 HP |
| Capacity | 16.8 CFM, 22.4 CFM, 33.5 CFM, 46.6 CFM |
| Pressure | 175 PSI |
| Tank Size | None, 80 gallon, 120 gallon |
| Voltage | 208/3/60, 230/3/60, 460/3/60, 575/3/60, 208/1/60, 230/1/60 |
