FS-Curtis RSD Series Rotary Screw Air Compressor

Product overview

Built around your operating requirements.

Description

The FS-Curtis RSD Series Rotary Screw Air Compressor has a plug-and-play design that allows for easy installation in a wide range of applications. The standard machine has no cabinet to work around, giving easy access to all components. Features like long-life consumables, factory-filled synthetic oil, and an oil level sight glass help reduce maintenance time. The multi-stage oil separation system and the heavy duty oil filter with bypass help ensure long-term operation.

Overview and Features

Features

50 to 300 HP
174 to 1360 CFM
NEMA Premium Efficiency ODP motor
Gear drive
NEMA 1 full voltage starter
Pressure ratings:
- 100, 125, 150, and 175 PSI (50 to 100 HP)
- 100, 150, and 150 PSI (125 to 300 PSI)
460/3/60 voltage for all models

Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.

Available specifications

Horsepower	50 HP, 60 HP, 75 HP, 100 HP, 125 HP, 150 HP, 200 HP, 250 HP, 300 HP
Capacity	228 CFM at 100 PSI, 212 CFM at 125 PSI, 188 CFM at 150 PSI, 174 CFM at 175 PSI, 295 CFM at 100 PSI, 272 CFM at 125 PSI, 227 CFM at 150 PSI, 200 CFM at 175 PSI, 357 CFM at 100 PSI, 330 CFM at 125 PSI, 312 CFM at 150 PSI, 251 CFM at 175 PSI, 457 CFM at 100 PSI, 438 CFM at 125 PSI, 374 CFM at 150 PSI, 337 CFM at 175 PSI, 554 CFM at 100 PSI, 522 CFM at 125 PSI, 465 CFM at 150 PSI, 731 CFM at 100 PSI, 723 CFM at 125 PSI, 544 CFM at 150 PSI, 930 CFM at 100 PSI, 860 CFM at 125 PSI, 770 CFM at 150 PSI, 1218 CFM at 100 PSI, 1050 CFM at 125 PSI, 970 CFM at 150 PSI, 1360 CFM at 100 PSI, 1350 CFM at 125 PSI, 1050 CFM at 150 PSI
Configuration	Base Mount - Open
Voltage	460/3/60 (standard), 200/3/60, 230/3/60, 575/3/60
Additional Options	1-TEFC Motor, NEMA-4 panel, Wye-Delta Starter, Water Cooled (includes TEFC Motor and NEMA-4 Panel), Factory Filled with Food Grade Oil

Horsepower

50 HP, 60 HP, 75 HP, 100 HP, 125 HP, 150 HP, 200 HP, 250 HP, 300 HP

Capacity

228 CFM at 100 PSI, 212 CFM at 125 PSI, 188 CFM at 150 PSI, 174 CFM at 175 PSI, 295 CFM at 100 PSI, 272 CFM at 125 PSI, 227 CFM at 150 PSI, 200 CFM at 175 PSI, 357 CFM at 100 PSI, 330 CFM at 125 PSI, 312 CFM at 150 PSI, 251 CFM at 175 PSI, 457 CFM at 100 PSI, 438 CFM at 125 PSI, 374 CFM at 150 PSI, 337 CFM at 175 PSI, 554 CFM at 100 PSI, 522 CFM at 125 PSI, 465 CFM at 150 PSI, 731 CFM at 100 PSI, 723 CFM at 125 PSI, 544 CFM at 150 PSI, 930 CFM at 100 PSI, 860 CFM at 125 PSI, 770 CFM at 150 PSI, 1218 CFM at 100 PSI, 1050 CFM at 125 PSI, 970 CFM at 150 PSI, 1360 CFM at 100 PSI, 1350 CFM at 125 PSI, 1050 CFM at 150 PSI

Configuration

Base Mount - Open

Voltage

460/3/60 (standard), 200/3/60, 230/3/60, 575/3/60

Additional Options

1-TEFC Motor, NEMA-4 panel, Wye-Delta Starter, Water Cooled (includes TEFC Motor and NEMA-4 Panel), Factory Filled with Food Grade Oil
