Mi-T-M Industrial Two Stage Diesel Air Compressor/Generator Combo
This diesel combination unit has the convenience of two machines in one providing power for most any industrial and contractor need.
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
A reliable Kohler diesel engine powers this beast. Developed for the agricultural and construction industries, this model can take anything you throw at it. Mount it on the back of a service truck and take it to the most remote locations to get big jobs done.
Overview and Features
Features
- 16.4 CFM @ 90 PSI / 15.7 CFM @ 175 PSI
- Electric Start – batter, box and cables not included
- Glow plug equipped for easy starting in cold temperatures
- Cast iron compressor pump
- Splash lubricated
- Stainless-steel braided discharge hose
- Large canister intake filter
- Oil level sight indicator
- Brushless alternator
- Total harmonic distortion (THD) less than 6%
- 100% copper windings
- (2) NEMA 5-20R 120V, 20A and (1) NEMA L6-20R 240V, 20A receptacles
- Powder coated ASME receiver tank
- 3/16″ base plate to reduce vibration
- Powder coated two-piece belt guard
- Regulator and two gauges for tank and outlet pressure
- Manual drain valves for proper maintenance
- 16.5″ fly wheel
- Quality pilot valve unloader
- ASME Boiler and Pressure Vessel Code – UM
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
Detailed specifications are available on request.
