Chicago Pneumatic
Chicago Pneumatic WISAIR 20-75 Oilless Rotary Screw Air Compressor
20 to 75 hp, Produces ISO 8573-1 (2010) Class Zero certified oil-free air
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Chicago Pneumatic WISAIR 20-75 Oilless Rotary Screw Air Compressor uses inverter technology to eliminate no load power losses, along with friction free hydrodynamic bearings lubricated by clean, filtered lubricant. A soft start up process reduces rotor stress. Compression is optimized by the low air discharge temperatures, optimized rotor profiles and no bearing losses. The drive train is direct driven.
Overview and Features
Features
- Base mount
- 20 to 75 HP
- 101.5 psi pressure rating (100-188 MAX PSI)
- 45 to 310 CFM capacity
- 460/3/60 voltage
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Configuration | Base mount |
|---|---|
| Horsepower | 20 HP, 25 HP, 30 HP, 40 HP, 50 HP, 75 HP |
| Capacity | 45 to 107 ACFM, 48 to 114 ACFM, 48 to 139 ACFM, 48 to 175 ACFM, 92 to 223 ACFM, 92 to 310 ACFM |
| Pressure | 100 PSI (100-188 MAX PSI) |
| Voltage | 460/3/60 |
