Hertz IMPETUS Series Rotary Screw Air Compressor
Air cooled oil injected, two-stage, direct coupled, fixed speed air compressor, 125 to 430 HP
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Hertz IMPETUS Series Rotary Screw Air Compressor is an air cooled design that features a two-stage screw block for increased efficiency and flow rates. This fixed speed compressor offers capacities from 494 to 2242 CFM and is available in 100, 125, 150, and 175 PSI pressure ratings (depending on CFM selected). The IMPETUS Series also features a Wye Delta starter and TEFC IP55 motor as standard.
Overview and Features
Features
- 125 to 430 HP models
- 494 to 2242 CFM
- 100, 125, 150, and 175 PSI max pressure (depending on selected CFM)
- 460/3/60 voltage
- Air cooled design
- Wye Delta starter
- TEFC IP55 motor
Tech Specs
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Horsepower | 125 HP, 150 HP, 180 HP, 220 HP, 250 HP, 270 HP, 340 HP, 430 HP |
|---|---|
| Capacity | 631 CFM, 628 CFM, 497 CFM, 494 CFM, 790 CFM, 783 CFM, 626 CFM, 946 CFM, 937 CFM, 813 CFM, 1106 CFM, 1059 CFM, 957 CFM, 917 CFM, 1262 CFM, 1249 CFM, 1086 CFM, 998 CFM, 1606 CFM, 1456 CFM, 1286 CFM, 1077 CFM, 1823 CFM, 1703 CFM, 1567 CFM, 1444 CFM, 2242 CFM, 2103 CFM, 1859 CFM, 1673 CFM |
| Pressure | 100 PSI, 125 PSI, 150 PSI, 175 PSI |
| Lubricant | Smart Oil 6000 (Standard), Food Grade Oil |
| Startup | Startup Included |
