Compressed Air Systems
Compressed Air Systems Industrial Diesel Stationary Cube Piston Air Compressor
442 CC diesel motor, 15 ACFM at 175 PSI, electric starter
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Compressed Air Systems Industrial Diesel Stationary Cube Piston Air Compressor provides a functioning compressor without the need to purchase an air receiver. If the application site already has a certified functional air receiver, the Cube Piston Air Compressor can be installed next to the existing tank with the air discharge line connected. If there is no existing tank or the existing tank is no longer certified or functional, a standalone tank can be added to the system.
Elite package includes:
- Belt guard mounted air after cooler
- Low oil monitor
- High-temp stainless steel flex discharge line
- Vibration isolation mounting pads
Overview and Features
Features
- 442 CC diesel motor
- Capacities:
- 15 ACFM at 175 PSI
- 18 ACFM at 100 PSI
- Splash or pressure lubricated options
- Elite package includes:
- Belt guard mounted air after cooler
- Low oil monitor
- High-temp stainless steel flex discharge line
- Vibration isolation mounting pads
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Package | Standard, Elite (belt guard after cooler, low oil monitor, discharge line, mounting pads) |
|---|---|
| Pump Type | Splash lubricated, Pressure lubricated |
