Industrial Gold DR Series Rotary Screw Air Compressor
5 to 10 HP duplex compressor with open frame design, tank mounted on 120 gallon air receiver
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Industrial Gold DR Series rotary screw air compressor is available from 5 to 10 HP for 100% continuous duty applications. The compressor is designed for quiet operation, with low tip speeds on air end for long life.
The DR Series features UL control components, easy to read and access gauges, 8,000 hour factory filled premium synthetic fluid, stainless steel discharge lines, omega profile rotors, IEC contactors, and a spin-on separator and oil filter. The horizontal, 120 gallon air receiver is ASME powder coated. An extended oil drain with ball valve allows for easy service.
Overview and Features
Features
- 32 to 78 CFM capacity
- 150 PSI pressure rating
- Voltage:
- 208-230
- 208-230/460
- 1 or 3 phase
- Less than 3 ppm oil carryover
- Automatic tank drain
- Baldor electric motors
- Air cooled aftercooler
- Heavy-duty air filter
- Single control solenoid operation
- SMART contact controls
- Timed shutdown
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Configuration | Tank mount, open |
|---|---|
| Horsepower | 5 HP, 7.5 HP, 10 HP |
| Capacity | 32 CFM, 52 CFM, 78 CFM |
| Pressure | 150 PSI |
| Voltage | 208-230/1/60, 208-230/460/3/60 |
| Tank Size and Orientation | 120 gallon, horizontal |
