Quincy Compressor QAF Series Carbon Filter
Activated carbon adsorber reducing the contamination level of compressed air to 0.003 PPM by weight
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Quincy Compressor QAF Series carbon filter removes hydrocarbon vapors and organic orders. The element contains selected activated carbons specifically developed for compressed air purification. The finely ground, activated carbons are imbedded in the binder free, microfiber fleece creating a highly efficient adsorbing surface. The QAF Series is ISO 8573 compliant and will reduce the contamination level of compressed air to 0.003 PPM by weight. Available in capacities from 6 to 10,500 CFM, the QAF Series features a push-fit proprietary element, dead-stop head-to-bowl connection to ensure safe closure, and a manual drain.
For optimum performance, 0.003 PPM adsorbers should be installed downstream of an air dryer and polishing coalescer.
Overview and Features
Features
- 6 to 10,500 CFM capacity
- 0.7psi pressure loss
- 300psi max pressure
- 1,000 hour lifetime
- ISO 8573
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Capacity | 6 CFM, 15 CFM, 25 CFM, 32 CFM, 50 CFM, 70 CFM, 85 CFM, 105 CFM, 125 CFM, 175 CFM, 280 CFM, 321 CFM, 450 CFM, 700 CFM, 850 CFM, 900 CFM, 1,250 CFM, 1,500 CFM, 1,800 CFM, 2,400 CFM, 3,000 CFM, 3,800 CFM, 4,500 CFM, 6,000 CFM, 8,500 CFM, 10,500 CFM |
|---|---|
| Connection | 1/8in NPT, 1/4in NPT, 3/8in NPT, 1/2in NPT, 3/4in NPT, 1in NPT, 1 1/4in NPT, 1 1/2in NPT, 2in NPT, 2 1/2in NPT, 3in NPT, 4in flange, 6in flange, 8in flange |
