OZEN OFLHG-H Series High Pressure Compressed Air Filter
725 or 5075 PSIG options, 42 to 2470 SCFM, weldless housing design
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The OZEN OFLHG-H Series High Pressure Compressed Air Filter provides high-quality air, as high-pressure applications require. The reinforced wall thickness ensures high-pressure performance.
Overview and Features
Features
- 42 to 2470 SCFM
- 725 or 5075 PSIG pressure-rated options
- 725 PSIG: Aluminum housing
- 5075 PSIG: Carbon steel housing
- Weldless housing design
- Filtration Grades:
- A: Activated Carbon – 0.01 micron particulate, 0.003 mg/m³ oil (not available with high-temp)
- P: Pre-Filter – 5 micron particulate, 5 mg/m³ oil
- X: General Purpose – 1 micron particulate, 0.5 mg/m³ oil
- Y: Oil Removal – 0.01 micron particulate, 0.01 mg/m³ oil
- NPT threaded connections
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Pressure Rating | 725 PSIG - Aluminum Housing, 5075 PSIG - Carbon Steel Housing |
|---|---|
| Capacity | 42 SCFM, 125 SCFM, 250 SCFM, 350 SCFM, 500 SCFM, 940 SCFM, 1470 SCFM, 1765 SCFM, 60 SCFM, 175 SCFM, 700 SCFM, 1317 SCFM, 2058 SCFM, 2470 SCFM |
| Filter Element | Pre-Filter (5 micron particulate, 5 mg/m³ oil), General Purpose (1 micron particulate, 0.5 mg/m³ oil), Oil Removal (0.01 micron particulate, 0.01 mg/m³ oil), Activated Carbon (0.01 micron particulate, 0.003 mg/m³ oil) |
| Connection Size | 1/4" NPT, 1/2" NPT, 3/4" NPT, 1" NPT, 1-1/2" NPT, 2" NPT, 2-1/2" NPT |
