FS-Curtis DLM Series Desiccant Air Dryer
Heatless, low flow air dryers with an inlet flow range of 13 to 40 scfm and an operating pressure range of 50 to 150psig
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The FS-Curtis DLM Series is a line of heatless, low flow desiccant air dryers designed for applications such as labs hospitals, and high tech installations due to the output of clean, dry air. These desiccant air dryers operate in a range of 13 to 50 scfm and can protect air systems exposed to temperatures below freezing. The fully enclosed wall-mounted package delivers dew points of ISO 8573.1 Class 1 and Class 2 and contains clean, streamlined piping.
Overview and Features
Features
- Inlet flow range: 13 to 40 scfm
- Operating pressure range: 50 to 150psig
- Standard voltage 115/1/60
- Enclosed design
- Meets ISO 8573.1 Class 1 and Class 2
- Front-mounted, at-a-glance control panel
- Maximum inlet temperature: 120°F
- 1/2in NPT connections
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Inlet Flow Options | 13 scfm, 18 scfm, 21 scfm, 27 scfm, 40 scfm |
|---|
