FPZ JDK Series Linear Compressor
1 to 4.2 CFM, 115V voltage, oil free design
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The FPZ JDK Series Linear Compressor features lower power consumption and increased airflow. The activated electromagnets put the magnet into oscillation movements. The magnet, which moves back and forth between the electromagnets at the same frequency as that of the power supply changes the valve box volume, creating pressure or vacuum. Internal pump temperatures are lowered resulting in extended diaphragm life. The JDK series is ul listed for outdoor operation.
Applications:
- Onsite wastewater treatment plant
- Air mattresses
- Aquaculture aeration
- Ink jet printers
- Circulation therapy
- Blood cuff monitors
- Air sampling/monitoring
- Liquid agitation
- Vacuum tweezers
Overview and Features
Features
- 1 to 4.2 CFM
- 1 to 1.6 CFM models rated at 1.7 PSI
- 2.3 to 4.2 CFM models rated at 2.9 PSI
- 115V voltage
- Oil free design
- ul listed for outdoor use
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Capacity | 1 CFM at 1.7 PSI, 1.3 CFM at 1.7 PSI, 1.6 CFM at 1.7 PSI, 2.3 CFM at 2.9 PSI, 3 CFM at 2.9 PSI, 3.5 CFM at 2.9 PSI, 4.2 CFM at 2.9 PSI |
|---|---|
| Alarm | None, With Alarm |
