Compressed Air Systems Industrial Gas Stationary Cube Piston Air Compressor
Includes centrifugal unloader and discharge cooling manifold
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Compressed Air Systems Industrial Gas Stationary Cube Piston Air Compressor provides a functioning compressor without the need to purchase an air receiver. If the application site already has a certified functional air receiver, the Cube Piston Air Compressor can be installed next to the existing tank with the air discharge line connected. If there is no existing tank or the existing tank is no longer certified or functional, a standalone tank can be added to the system.
Elite package includes:
- Belt guard mounted air after cooler
- Low oil monitor
- High-temp stainless steel flex discharge line
- Vibration isolation mounting pads
Overview and Features
Features
- 5.5 to 14 HP
- 100 to 175 PSI
- 13 to 24 ACFM @ 100 PSI
- Easy open inline check valve
- Easy service belt guard
- Easy to read oil sight glass
- Electric or pull start drive engine
- Extended oil drain tube
- Inner stage cooler
- Multiplexing capability
- Elite package includes:
- Belt guard mounted air after cooler
- Low oil monitor
- High-temp stainless steel flex discharge line
- Vibration isolation mounting pads
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Package | Standard, Elite (belt guard after cooler, low oil monitor, discharge line, mounting pads) |
|---|---|
| Horsepower | 5.5 HP, 13 HP, 14 HP |
| Capacity | 13 ACFM @ 100 PSI, 23 ACFM @ 175 PSI |
| Pressure Rating | 100 PSI, 175 PSI |
| Starter | Pull, Electric |
| Pump Type | Splash lubricated, Pressure lubricated |
