Clean Resources BPD Series Blower Purge Regenerative Desiccant Air Dryer
500 to 10000 CFM capacity dryer with centrifugal blower that uses ambient air to regenerate desiccant
Request a tailored quote
Tell our team about your pressure, flow, voltage, and installation requirements.
Product overview
Built around your operating requirements.
Description
The Clean Resources BPD Series Blower Purge Regenerative Desiccant Air Dryer features an automatic system that uses a centrifugal blower and a high-efficiency heater to pull in ambient air and pass it through the heater. This eliminates the need to use valuable compressed dry air for desiccant regeneration. The hot air stream from the blower flows opposite the drying flow direction. Hot air above 400°F regenerates the moisture-laden desiccant bed and strips it completely of moisture. The control system monitors the dewpoint and adjusts the heating/regeneration accordingly, providing significant energy savings. The heater circuit is completely insulated, ensuring maximum heating efficiency.
Overview and Features
Features
- 500 to 10000 CFM capacities
- >400°F air for bed regeneration
- 200 PSIG (500 to 1500 CFM) and 150 PSIG (2000 to 10000 CFM) pressure vessels
- Stainless steel inlet/outlet diffuser
- Flow activated, high-temperature check valve (800 CFM and up)
- Insulated heater circuit
- Dryer backup heatless mode
- Fully field-adjustable heater temperature setpoints
- Nema 12 electrical enclosure standard
- (Nema 4 and Nema 4X options available)
- Failure-to-switch alarm standard
- UL and CUL electrical certifications
Available configuration, accessories, delivery, and commissioning requirements will be confirmed during quotation.
Available specifications
| Capacity | 500 CFM, 650 CFM, 800 CFM, 1000 CFM, 1250 CFM, 1500 CFM, 2000 CFM, 2500 CFM, 3000 CFM, 3500 CFM, 4000 CFM, 5000 CFM, 6000 CFM, 7000 CFM, 8000 CFM, 9000 CFM, 10000 CFM |
|---|---|
| Filter | None, Add mounted filter |
| Bypass | None, Add 3 valve bypass, Duplex Pre-Filter and Duplex After Filter with 9 valve bypass |
| NEMA Rating | NEMA 12, NEMA 4, NEMA 4X Stainless Steel |
| Visual Moisture Indicator | None, Add Visual Moisture Indicator |
| Demand Cycle Control with Dewpoint Monitor | None, Add Demand Cycle Control with Dewpoint Monitor |
| Control Options | SIEMENS TS-HMI, PLC Control with Remote Communication and Allen Bradley Color Touchscreen |
| Stainless Steel Control Tubing | None, Add Stainless Steel Control Tubing |
| Low Ambient Package | None, Add Low Ambient Package |
| Tower and Hot Piping Insulation | None, Add Tower and Hot Piping Insulation |
| Voltage | 460/3/60, 575/3/60, 400/3/50 |
| Temperature Gauge | None, Add Temperature Gauge |
| Pressure Gauge | None, Add Pressure Gauge |
| Subzero Package | None, Add Subzero Package |
| As-built Drawing | None, Add As-built Drawing |
